Profile: Hais lus rub lub siab sensor yog nruab nrog cov neeg siab, tsis tshua muaj profile, zoo zog, yooj yim installation, muaj zog tiv thaiv eccentric load peev, thiab yog dav siv nyob rau hauv lub zog ntsuas ntawm txoj siv scale, hopper scale, thiab ntau yam hnyav ntsuas tshuab.
Technical Parameter
| rhiab heev | 2.0 ± 0.05mV / V |
| Nonlinear | ± 0.03% FS |
| Hsteresis | ± 0.03% FS |
| repeatability | 0.03% FS |
| Ntsig | ± 0.03≤% FS / 30 feeb |
| Zero tso zis | ± 1≤% FS |
| Zero kub coefficient | +0.03≤%FS/10 ℃ |
| rhiab heev kub coefficient | +0.03≤%FS/10 ℃ |
| Kev khiav hauj lwm qhov kub thiab txias | -20 ℃ ~ + 80 ℃ |
| Input kuj | 750 ± 20Ω |
| Cov zis tsis kam | 700 ± 5Ω |
| Kev nyab xeeb tshaj | 150≤% RO |
| Rwb thaiv tsev tsis kam | ≥5000MΩ (50VDC) |
| Reference excitation voltage | 5V-12V |
| Txoj kev txuas hlau | Liab-INPUT(+) Dub- INPUT(-) Green-OUTPUT(+)White-OUTPUT(–) |
